¶ Filament Not Sticking to the Build Plate — X-Plus 4
Poor first-layer adhesion is one of the most common printing issues.
A properly bonded first layer is essential because all subsequent layers rely on it as a foundation. If the first layer does not adhere correctly, the print may fail.
¶ Z Offset Adjustment
If the first layer does not stick to the build plate, the nozzle-to-build plate distance may be incorrect.
Example of poor adhesion (nozzle too far from the build plate):
Below are examples of first-layer conditions:
- Left: Nozzle too far from the build plate
- Middle: Correct Z offset
- Right: Nozzle too close to the build plate
¶ How to Adjust Z Offset
If gaps appear between first-layer lines during printing, the nozzle is too far from the build plate.
The Z offset defines the distance between the nozzle and the build plate.
Recommended adjustment method:
- Start a print.
- During the first layer, tap the Z Offset icon on the screen.
- Adjust in small increments (recommended: 0.05 mm per adjustment).
- Observe the first layer before making further changes.
Note:
- There is a short delay after each adjustment.
- Do not tap repeatedly too quickly.
- The adjusted value is saved automatically.
¶ Clean the Build Plate
A dirty or greasy surface can cause adhesion problems.
For cleaning instructions, refer to:
Build Plate Cleaning Guide
¶ Cleaning recommendations
- PEI surface: Clean using isopropyl alcohol (IPA) or warm water.
- Glue stick: Apply a thin, even layer to improve adhesion.
- Hairspray: A light coat (medium hold) may improve adhesion in some cases.
If adhesion issues persist after calibration and cleaning, contact after-sales support:
